All capacities are based on the use of Rollforming quality Mild Steel. All specifications, dimensions & weights are approximate & are to be used as a guide. Colours may vary.
All prices are subject to delivery costs and applicable VAT. W. Neal Services Ltd reserves the right to alter any specifications. Please note products are NOT to scale. E&OE.
WNS
Lever Cropper/Shear.
Blade: 200mm.
Flat Steel: 90mm x 14mm.
Round Steel: 22mm.
Square Steel: 20mm.
Angle Steel: 60mm x 7.0mm.
T-Beam: 60mm x 7.0mm.
Plate Steel: 10mm.
(LC14)
WNS
Lever Cropper/Shear.
Blade: 200mm.
Flat Steel: 100mm x 10mm.
Round Steel: 16mm.
Square Steel: 16mm.
Angle Steel: 40mm x 6.0mm.
T-Beam: 40mm x 6.0mm.
Plate Steel: 8.0mm.
(LC10)
WNS
Lever Cropper/Shears.
Blade: 300mm.
Flat Steel: 3.0mm.
Round Steel: 10mm.
(LC300)
Blade: 150mm.
Flat Steel: 2.0mm.
Round Steel: 6.0mm - 8.0mm.
(LC150)
WNS
Lever Cropper Replacement Blades.
300mm Blade (LC300)
150mm Blade (LC150)
WNS
Throatless Shear/Curved Blade Cropper.
100mm Blade x 1.2mm Capacity.
(TS100)
2.0mm Capacity Model also available.
WNS
Circular Saw Blades.
315mm Blade.
40mm Diameter Hole Centre.
220 teeth & 260 teeth available.
(CS Blades)
WNS
Band Saw.
Blade Length: 2450mm
Blade Diameter: 27mm
Maximum Thickness: 0.9mm.
Motor: 0.75/1.1.0kW
415v , 3 Phase.
(BS2450)
Spare Blades also available.
WNS
Circular Cut Off Saw.
Blade Diameter: 315mm.
Circular Capacity: 100mm.
Rectangular Capacity: 140mm x 90mm.
Double Clamping.
c/w Stand.
c/w Coolant Pump.
Motor: 18 & 36 RPM.
415v, 3 Phase.
(CS315)
Draco Cordless Cutting Tools.
Cuts through Spiral Ducting & Pittsburgh Lock.
Ideal for multiple seams including spiral
ducting, seams, mesh and wire etc.
c/w 2 Batteries, Charger & Case.
(AK3514-2) 200mm Radius.
(AK3514-7R) 45mm Radius.
Draco Electric Cutting Tools.
Ideal for cutting smaller diameter holes/circles in
metal and the tool cuts formed parts without
distortion or straightening.
(3514-2) 200mm Radius.
(3541-7R) 45mm Radius.
Manufacturers of Rollformers & Sheet Metal Working Machinery
00 44 (0) 1702 542554
00 44 (0) 1702 542558
