All capacities are based on the use of Rollforming quality Mild Steel. All specifications, dimensions & weights are approximate & are to be used as a guide. Colours may vary.
All prices are subject to delivery costs and applicable VAT. W. Neal Services Ltd reserves the right to alter any specifications. Please note products are NOT to scale. E&OE.
WNS
Power Ring Rollers on Stand.
c/w 1 Set of Dies.
Top Roll: 75mm Wide x 98mm Diameter.
Bottom Rolls: 75mm Wide x 118mm Diameter.
Shaft Diameter: 30mm.
415v, 3 Phase.
(PRR75)
240v, Single Phase.
(PRR75sp)
WNS
Ring Roller on Stand.
c/w 1 Set of Dies.
Top Roll: 75mm Wide x 98mm Diameter.
Bottom Rolls: 75mm Wide x 118mm Diameter.
Shaft Diameter: 30mm.
Standard Tooling is Capable of
Forming, Flat, Round and Angle Bar.
(RR75)
WNS
Ring Roller Tooling.
Suitable for the PRR75, PRR75sp and RR75.
Tube and Pipe from 15mm to 60mm.
Universal Die Kit also available.
(RR75-Dies)
WNS
Ring Roller.
Roll Diameter: 25mm Wide x 32mm Diameter.
Flat Bar: 25mm Wide x 5.0mm Thick.
Round Bar: 6.5mm Diameter.
Minimum Ring Diameter: 75mm.
(RR25)
WNS
Ring Roller.
Roll Diameter: 25mm Wide x 32mm Diameter.
Flat Bar: 25mm Wide x 4.0mm Thick.
Round Bar: 6.5mm Diameter.
Minimum Ring Diameter: 75mm.
(RR25B)
WNS
Hand Scroll Bender.
Flat: 30mm x 10mm.
Round: 10mm.
Square: 10mm².
Scroll Size Diameters: 63mm, 115mm &
165mm.
(SB30)
Steelworker Compact 50.
Includes tooling for punching, shearing,
angle cutting, section cutting & notching, 10
Sets of Round Punches up to 38mm diameter.
Additional tooling also available separately.
4 Stations, Single cylinder, 40 ton Capacity.
3 Phase. (SW50_kland)
Single Phase. (SW50_kland/sp)
Hydraulic Punching Machine.
280mm Throat.
Max Capacity 24mm x 15mm.
c/w 10 Sets of Round Punches & Dies up
to 38mm Diameter.
(HP50P_kland)
WNS
Bar & Scroll Bender.
Bending Strength: 28½ Tons p/sq inch.
Flat: 30mm x 8.0mm.
Round: 15mm.
Square: 13mm².
Scroll Size Diameter: 125mm.
(SB40)
WNS
Form / Bar Bender.
Flat: 100mm x 3.0mm Capacity.
Round: Up to 12mm Capacity.
Square: Up to 8.0mm Capacity.
(FB100)
Manufacturers of Rollformers & Sheet Metal Working Machinery
00 44 (0) 1702 542554
00 44 (0) 1702 542558
