WNS Box & Pan Folder 1346mm x 2.5mm

Box & Pan Folders


Description

WNS BOX & PAN FOLDER (BPF1340J) has a folding length of 1346mm and can accommodate mild steel sheets up to 2.5mm thick. The BPF1340J has a maximum lift of 50mm, a bed height of 900mm and a folding angle between 0-135°. It also comes complete with 11 fingers and 2 x counterbalance weights for assisted operation.

View Literature



Additional information

Weight 1250 kg
SPECIFICATIONS
Model: BPF1340J
Folding Length: 1346mm
Maximum Thickness: 2.5mm Mild steel
Folding Angle: 0 – 135˚
Maximum Lift (apx): 50mm
Bed Height (apx): 900mm
Finger Sizes (x 11): 76.2mm (x1)
101.6mm (x2)
127mm (x6) 152.4mm (x2)
Dimensions – machine w/ weights (apx): 2740mm x 1780mm x 1560mm (l x w x h)
Dimensions – packing (apx): 2000mm x 760mm x 1140mm (l x w x h)
Weights – net/gross (apx): 850Kg/980Kg



All capacities are based on the use of Rollforming quality Mild Steel. All specifications, dimensions & weights are approximate & are to be used as a guide. Colours may vary. All prices are subject to delivery costs and applicable VAT. W. Neal Services Ltd reserves the right to alter any specifications. Please note products are not to scale. E&OE.

SKU: BPF1340J

WNS Box & Pan Folder 1346mm x 2.5mm

• Hand Operated Box and Pan
• 1346mm Folding Length
• 2.5mm Capacity Mild Steel
• c/w 11 Fingers
• c/w 2 Counterbalance Weights
