Manufacturers of Rollformers & Sheet Metal Working Machinery

W. Neal Services Ltd

Manufactured by W. Neal Services Ltd
WNS 20swg (1.0mm) Pittsburgh Lock Rollformers are 5 station machines.  They are principally used in the HVAC industry for joining sheet metal at right angles on straight and curved duct sections.  Pittsburgh Lock Rolls, Auxiliary Shafts and an Auto Guide Flanging Attachment are fitted as standard.(And if you think needed).

WNS 20swg (1.0mm) Pittsburgh Lock Rollformer (RF20)
Image is not available

Manufactured by W. Neal Services Ltd
WNS 16swg (1.6mm) Pittsburgh Lock Rollformers are 7 station machines. They are principally used in the HVAC industry for joining sheet metal at right angles on straight and curved duct sections. Pittsburgh Lock Rolls & Auxiliary Shafts are fitted as standard with the option of a Flanging Attachment if required.

WNS 16swg (1.6mm) Pittsburgh Lock Rollformer (RF16)
Image is not available

Manufactured by W. Neal Services Ltd
WNS 16swg (1.6mm) POWER FLANGERS are principally used for forming a right angle flange on curved, straight and irregular shapes.  The machines are fitted with a tilting head to enable complete circles to be formed.  WNS Power Flangers are manufactured with hardened top plates, shafts, forming rolls, gears and guide fences.

WNS 16swg (1.6mm) Power Flanger (PF16)
Image is not available

WNS PITTSBURGH LOCK SEAM CLOSERS / LOCKERS (SC10) & (SC12) are the ideal machines for use with Lockformers/Rollformers for closing straight or curved Pittsburgh Lock seams on ducting.

WNS Pittsburgh Lock Seam Closers / Lockers (SC10) & (SC12)
Image is not available

Manufactured by W. NEAL SERVICES LTD
WNS / INGERSOLL RAND 18swg (1.2mm) Pittsburgh Lock Air Closing Hammer is used for closing 18swg Pittsburgh Lock and lighter material. The force and speed of the hammer blows can be regulated by the depression of the trigger.

WNS / INGERSOLL RAND 18swg (1.2mm) Pittsburgh Lock Air Closing Hammer (AH18)
Image is not available

Manufactured by W. NEAL SERVICES LTD
WNS 20swg (1.0mm) FLANGE FOLDERS are the ideal machines when forming regular sized flanges. Designed to create a right angle flange from 7.0mm to 25mm, this machine provides quick and easy repeat flanges suitable for Pittsburgh Lock Seams. There is no need to keep measuring, or clamping. WNS Flange Folders also have the advantage of being ‘open ended’ allowing the user to also form inside flanges.

WNS 20swg (1.0mm) Flange Folder (FF20)
Image is not available

Manufactured by W. NEAL SERVICES LTD
WNS Power Swager (PS280) are principally used for Swaging, Beading, Wiring, Crimping and Forming of sheet metal.  The PS280 Power Swager has a 280mm Throat and can accommodate mild steel sheet up to 2.0mm thick. This machine comes complete with 1 Set of 3/8″ Swage Rolls. The PS280 has a variable speed and has a low voltage Forward & Reverse foot pedal.

WNS Power Swager c/w 1 Set of 3/8″ Swage Rolls 2.0mm Capacity (PS280)
Image is not available

Manufactured by W. NEAL SERVICES LTD
WNS Initial Pinch Hand Bending Rolls are principally used for rolling curves or tubes in sheet metal.  Available from 1020mm long to 2000mm long, accommodating sheet up to 1.5mm.

WNS Initial Pinch Hand Bending Rolls 2000mm x 75mm x 1.2mm Capacity (BR2000/75wns)
Image is not available

WNS BOX & PAN FOLDER (BPF2540J) has a folding length of 2540mm and can accommodate mild steel sheets up to 2.0mm thick. The BPF2540J has a maximum lift of 50mm, a bed height of 900mm and a folding angle between 0-135°. It also comes complete with 23 fingers and 2 x counterbalance weights for assisted operation.

WNS Box and Pan Folder (BPF2540J)
Image is not available
previous arrow
next arrow
Slider

W. Neal Services Ltd….

  • Manufacturers of Rollformers & quality sheet metal working machinery.
  • Over 30 Years in the industry.
  • Specialists in service & repair of many Rollformer brands such as Lockformer, Oliver, Shorte & more.
  • Spare parts stocked.
  • Extensive knowledge base.
  • Internationally recognised WNS brand.
  • Reconditioned machinery available.

WNS Pittsburgh Lock Seam
Closers / Lockers

• 0.50mm – 1.0mm Capacity (SC10)
• 0.75mm – 1.2mm Capacity (SC12)
Motor Power: 1400 Watts, 50/60Hz
Supply Voltage: 240v, Single Phase

DEMONSTRATION MODEL AVAILABLE
