ENGEL EUROPA I-FOLD DUCT COIL LINE (ECL05) offers most of the functionality of a conventional coil line with the advantage of a vastly reduced 3m x 2m floor space. The I-Fold gives the Operator the ability to use standard coil widths in multiple gauges up to 1.6mm and manufacturing ductwork to any sizes from a minimum of 120mm x 120mm.
This machine will produce flat sheet, “I” Shape, “U” Shape and fully wrapped duct. It’s fully hydraulic system is controlled by the Auto fold V8 control system specifically designed for the machine, input is through a dedicated 14″ touch screen controller using windows CE platform running the Autofold Standard Program.
Ductwork is produced at an average rate of 1 duct per 20 seconds, depending on the duct size; the I-Fold retains the same production rate of the bigger Autofold Machines.
Installation of the I-Fold can be carried out by the customer, as the machine is shipped complete and requires only one 3 phase power supply (no air is required).
This machine has been fully reconditioned and repainted comes complete with 2x uncoilers, new touch screen, and a 1 year warranty.
USED/RECONDITIONED
This is a used machine and is in full working order.
Please note: this machine is being sold on consignment from one of our customers.
UK standard delivery included
To offload, a forklift with 3.5 ton extension forks is required. If ordering a 5 ton coil then you will need a forklift that can accommodate this.
HIAB delivery can be arranged at an additional cost.
| SPECIFICATIONS | |
| Model: | ECL05 (I-FOLD) |
| Sheet Width: | 1500mm |
| Maximum Thickness: | 1.6mm Capacity Mild Steel |
| Minimum Duct Size: | 120mm x 120mm |
| Production Speed: | 1 Duct Per 20 Seconds |
| Supply Voltage: | 415v, 3 Phase Electrics, 25 Amp Supply & Circuit Breaker |
| Dimensions – machine (apx): | 2000mm x 3000mm x 1500mm (l x w x h) |
| Weight (apx): | 2.5 Tonne |
All capacities are based on the use of rollforming quality mild steel unless otherwise stated. All specifications, dimensions and weights are approximate and are to be used as a guide. Colours may vary. Please note photographs/drawings are not to scale. All prices are subject to delivery costs and applicable VAT.
W. Neal Services Ltd reserves the right to alter any specifications. For warranty terms please see our full Terms & Conditions. E&OE.
