Ma n u f a c t u r e d b y W. NEAL SERV I CES L TD
1000mm x 1.0mm Capacity.
Open Ended Folder ideal for use with
Rollformers / Lockformers.
(FF20)
WNS
20swg (1.0mm) FLANGE FOLDERS are the ideal machines when forming regular sized flanges. Designed to create
a right angle flange from 7.0mm to 25mm, this machine provides quick and easy repeat flanges suitable for Pittsburgh
Lock Seams. There is no need to keep measuring, or clamping. WNS Flange Folders also have the advantage of being
‘open ended’ allowing the user to also form inside flanges.
WNS
20swg (1.0mm) Flange Folder
Length:
Width:
Height:
Weights - net/gross:
1000mm
450mm
1000mm
50Kg/60Kg
Model:
Folding Length:
Maximum Thickness:
Minimum Flange Height:
Maximum Flange Height:
FF20
1000mm
1.0mm
7.0mm
25mm
SPECIFICATIONS
