All capacities are based on the use of Rollforming quality Mild Steel. All specifications, dimensions & weights are approximate & are to be used as a guide. Colours may vary.
All prices are subject to delivery costs and applicable VAT. W. Neal Services Ltd reserves the right to alter any specifications. Please note products are NOT to scale. E&OE.
for Right Angle Flange
415v, 3 Phase.
(PF16)
Manufacturers of Rollformers & Sheet Metal Working Machinery
00 44 (0) 1702 542554
00 44 (0) 1702 542558
Ma n u f a c t u r e d b y W. NEAL SERV I CES L TD
WNS
16swg (1.6mm) Power Flanger
WNS
16swg (1.6mm) POWER FLANGERS are principally used for forming a right angle flange on curved, straight and
irregular shapes. The machines are fitted with a tilting head to enable complete circles to be formed. WNS Power Flangers
are manufactured with hardened top plates, shafts, forming rolls, gears and guide fences.
CE
SPECIFICATIONS
Model:
Maximum Thickness: Material Thickness: Minimum Radius:
Speed:
Flange Height:
PF16
16swg (1.6mm)
6.0mm - 12mm
100mm
3m/min
6.0mm - 12mm
Flanging Direction:
Motor Power:
Supply Voltage:
Length:
Width:
Height:
Weights - net/gross:
Left to Right
415v, 3 Phase
1HP, 0.75kW
610mm
610mm
1050mm
100Kg/135Kg
