All capacities are based on the use of Rollforming quality Mild Steel. All specifications, dimensions & weights are approximate & are to be used as a guide. Colours may vary.
All prices are subject to delivery costs and applicable VAT. W. Neal Services Ltd reserves the right to alter any specifications. Please note products are NOT to scale. E&OE.
Manufacturers of Rollformers & Sheet Metal Working Machinery
00 44 (0) 1702 542554
00 44 (0) 1702 542558
Ma n u f a c t u r e d b y W. NEAL SERV I CES L TD
2500mm x 1.0mm Capacity. (BM2500)
2000mm x 1.0mm Capacity. (BM2000)
1550mm x 1.0mm Capacity. (BM1550)
1275mm x 1.0mm Capacity. (BM1275)
WNS
BEADING MACHINES are ideal for medium and small duct manufacturers. These machines have one pair of power
rolls and one pair of beading rolls. The sheet is placed on the entry table alongside the guide fences and then passed
through the machine. This makes the material stiffer and therefore enables stronger duct to be formed.
WNS
Beading Machines
CE
SPECIFICATIONS
Model:
Maximum
Length:
Maximum
Thickness:
Pitch
of Beads:
Width
of Beads:
Supply Voltage: Motor Power: Length: Width:
Height:
Weights -
net/gross:
BM2500 2500mm
1.0mm
300mm
10mm
415v, 3 Phase
3HP, 2.2kW 2840mm 700mm 1120mm 420Kg/570Kg
BM2000 2000mm
1.0mm
250mm
10mm
415v, 3 Phase
3HP, 2.2kW 2340mm 700mm 1120mm 750Kg/850Kg
BM1550 1550mm
1.0mm
215mm
10mm
415v, 3 Phase
2HP, 1.5kW 1975mm 700mm 1120mm 800Kg/850Kg
BM1250 1250mm
1.0mm
215mm
10mm
415v, 3 Phase
2HP, 1.5kW 1650mm 700mm 1120mm 280Kg/380Kg
