All capacities are based on the use of Rollforming quality Mild Steel. All specifications, dimensions & weights are approximate & are to be used as a guide. Colours may vary.
All prices are subject to delivery costs and applicable VAT. W. Neal Services Ltd reserves the right to alter any specifications. Please note products are NOT to scale. E&OE.
c/w Male & Female Rolls.
415v, 3 Phase.
(BPSL20)
Manufacturers of Rollformers & Sheet Metal Working Machinery
00 44 (0) 1702 542554
00 44 (0) 1702 542558
Ma n u f a c t u r e d b y W. NEAL SERV I CES L TD
WNS
BPSL Pliers. (SLP1)
CE
SPECIFICATIONS
Model:
Maximum Thickness:
Material Used:
Seam Width:
Flange Height:
Speed:
BPSL20
20swg (1.0mm)
45mm
16mm
10mm
8.0m/min
Motor Power:
Supply Voltage:
Length:
Width:
Height:
Weights - net/gross:
2HP, 1.5kW
415v, 3 Phase
1660mm
610mm
980mm
275Kg/355Kg
WNS
20swg (1.0mm) BUTTON PUNCH SNAP LOCK ROLLFORMERS are 9 station machines, principally used in the
HVAC industry, for joining sheet metal at right angles on straight and curved duct sections. The female ‘Lock’ is formed in
one pass. The flange, complete with the punched louvers, is formed on the auxiliary side of the machine. Simply snap the
flange into the female section. There is no knocking over of the edges as with the Pittsburgh Lock.
WNS
20swg (1.0mm) Button Punch Snap Lock Rollformer
