All capacities are based on the use of Rollforming quality Mild Steel. All specifications, dimensions & weights are approximate & are to be used as a guide. Colours may vary.
All prices are subject to delivery costs and applicable VAT. W. Neal Services Ltd reserves the right to alter any specifications. Please note products are NOT to scale. E&OE.
Manufacturers of Rollformers & Sheet Metal Working Machinery
00 44 (0) 1702 542554
00 44 (0) 1702 542558
Ma n u f a c t u r e d b y W. NEAL SERV I CES L TD
18swg (1.2mm) Capacity.
(AH18)
WNS / INGERSOLL RAND
Pittsburgh Lock Air Closing Hammer.
WNS
/
INGERSOLL RAND
18swg (1.2mm) PITTSBURGH LOCK AIR CLOSING HAMMER are used for closing 18swg
Pittsburgh Lock and lighter material. The force and speed of the hammer blows can be regulated by the depression of the
trigger. Light pressure on the trigger starts the hammer blows at a slow rate, whereas full power is reached when the
trigger is fully depressed. Speed can also be adjusted by the regulator on the bottom of the handle.
CE
SPECIFICATIONS
Model:
Maximum Thickness:
Hammer Head:
Hammer Speed:
Air Pressure:
Air Supply:
AH18
1.2mm
40mm Diameter
3500 BPM
90 PSI
3.0 CFM
Hose:
Air Inlet:
Length:
Width:
Height:
Weights - net/gross:
⅜” Diameter
¼” NPT
280mm
50mm
180mm
2.5Kg/3.0Kg
