All capacities are based on the use of Rollforming quality Mild Steel. All specifications, dimensions & weights are approximate & are to be used as a guide. Colours may vary.
All prices are subject to delivery costs and applicable VAT. W. Neal Services Ltd reserves the right to alter any specifications. Please note products are NOT to scale. E&OE.
WNS
16swg (1.6mm) Opening Roll.
(OR16)
Model:
Speed:
Flanging Attachment
Direction:
Motor Power: Supply Voltage: Length: Width:
Height:
Weights -
net/gross:
RF16
6.0m/min
Left to Right
2HP, 1.5kW
415v, 3 Phase 1450mm 615mm
1000mm (no FA)
1140mm (with FA)
250Kg/320Kg
CE
SPECIFICATIONS
Auxiliary
Rolls:
Pittsburgh
Lock Rolls
Inboard Fit:
Small
Pittsburgh
Lock*:
Drive
Cleat*:
Double
Seam*:
Plain
Seam*:
Right Angle
Flange*:
Standing
Seam*:
3 in 1*:
Safe
Edge*:
Closed
Double
Seam*:
Profiles:
(Standard)
Maximum
Thickness:
16swg (1.6mm)
0.8mm
1.0 mm
1.2mm
1.0mm
1.6mm
0.8mm
0.8mm
0.8mm
1.2mm
Material
Used:
32mm
(Subject to knockoveredge)
25mm
54mm
32mm
11mm
11mm
54mm
-
9.0mm
32mm
Seam
Width:
13mm
10mm
29mm
13mm
10mm
-
-
-
8.0mm
13mm
Flange
Height:
-
-
-
-
-
Max. 12mm
-
-
-
-
Seam
Height:
-
-
-
-
-
-
19mm
15mm
-
-
Manufacturers of Rollformers & Sheet Metal Working Machinery
00 44 (0) 1702 542554
00 44 (0) 1702 542558
Ma n u f a c t u r e d b y W. NEAL SERV I CES L TD
WNS
16swg (1.6mm) Pittsburgh Lock Rollformer.
415v, 3 Phase.
(RF16)
WNS
16swg (1.6mm) PITTSBURGH LOCK ROLLFORMERS are 7 station machines. They are principally used in the
HVAC industry for joining sheet metal at right angles on straight and curved duct sections. Pittsburgh Lock Rolls &
Auxiliary Shafts are fitted as standard with the option of a Flanging Attachment if required.
A ‘lock’ is formed in one pass and a flange is inserted into the pocket. The edge is then hammered over either manually or
with a WNS PITTSBURGH LOCK AIR CLOSING HAMMER
Additional forming rolls, such as DOUBLE SEAM
ROLLS, DRIVE CLEAT ROLLS, etc. can be fitted onto the Auxiliary Shafts. A FLANGING ATTACHMENT is also
available and can be fitted as an optional extra. This enables a right angle to be formed on curved, straight and irregular
shapes. The attachment is fitted with a tilting head to enable complete circles to be formed. WNS Rollformers are
manufactured with all steel side plates. The shafts, forming rolls, gears and guide fences are all hardened, and needle
bearings are fitted throughout.
* Optional Rolls which can be fitted to auxiliary shafts
Other Voltages
& Pneumatic
Operated Machines
available on request.
