WNS PITTSBURGH LOCK SEAM CLOSERS/LOCKERS (SC10-110v-1) are the ideal machines for use with lockformers/rollformers. The lockers are designed for closing straight or curved Pittsburgh lock seams on ducting, creating a continuous air tight seal. They have the ability to close Pittsburgh lock up to a maximum thickness of 1.0mm, automatically adjusting in accordance to the sheet thickness. The seam closers/lockers are powered by a 1400 watt speed adjustable motor, enabling the user to achieve high quality and tightly joined seams with ease.
SECONDS
This item is new however has slight imperfections to the storage case/box.
Pictures are stock images.
This has no impact on the item and the machine is in perfect working order
No returns on this item – sorry!
Viewing welcome prior to purchase.
Please Note: This is not a Trumpf F300 Seam Locker TruTool but a comparable alternative!
Not recommended for use on plastic coated materials as machine may leave marks or damage coating during operation.
Colours may vary.
| Weight | 10 kg |
|---|
| SPECIFICATIONS |
|
| Model: | SC10-110v-1 |
| Maximum Thickness: | 0.50mm – 1.0mm Capacity Mild Steel* |
| Flange Height: | 8.0mm – 11mm* |
| Minimum Inner Radius: | 150mm |
| Minimum Outer Radius: | 300mm |
| Working Speed: | 4.0m – 7.0m/min |
| Motor Power | 1400 Watts, 50/60Hz, Single Phase |
| Supply Voltage: | 110v |
| Dimensions – machine (apx): | 220mm x 170mm x 430mm (l x w x h) |
| Dimensions – packing (apx): | 470mm x 220mm x 320mm (l x w x h) |
| Weights – net/gross (apx): | 10Kg/10.8Kg |
All capacities are based on the use of rollforming quality mild steel unless otherwise stated. All specifications, dimensions and weights are approximate and are to be used as a guide. Colours may vary. Please note photographs/drawings are not to scale. All prices are subject to delivery costs and applicable VAT.
W. Neal Services Ltd reserves the right to alter any specifications. For warranty terms please see our full Terms & Conditions. E&OE.
